3 Axle Low Bed Trailer
3 Axle Low Bed Trailer

3 Axle Low Bed Trailer

16000 USD

Different Parameters, Different Price. Price Reference Only.



3 Axle Low Bed Trailer with Hydraulic Ramp, three styles of low bed trailer truck ramps, the most common is spring ramp.

SKU: 3 Axle Low Bed Trailer
MPN: TITAN9401TDP015
Brand: TITAN

3 axle low bed trailer description:

As a professional low bed trailer manufacturers, TITAN VEHICLE has provided many low bed trailer truck for many countries.

3 axle low bed trailer is widely used, mainly for medium and long-distance freight transportation. The lower the platform height of the low bed trailer truck, the better the stability and safety. 3 axle low bed trailer truck has a large carrying capacity when transporting extra high and medium cargo.

TITAN low bed trailer manufacturers very durable ones with high strength to meet the transport needs. We use high strength steel material to ensure the capacity, the load can be up to 60 to 150 ton payload.

3 Axle Low Bed Trailer Truck | Low Bed Trailer Manufacturers

3 Axle Low Bed Trailer Truck | Low Bed Trailer Manufacturers

3 Axle Low Bed Trailer Truck | Low Bed Trailer Manufacturers

3 Axle Low Bed Trailer Truck | Low Bed Trailer Manufacturers

3 Axle Low Bed Trailer Truck | Low Bed Trailer Manufacturers

3 Axle Low Bed Trailer Truck | Low Bed Trailer Manufacturers

3 Axle Low Bed Trailer Truck | Low Bed Trailer Manufacturers



Specification of low bed trailer truck:

Overall dimension: 16000mm * 3000mm *3400mm

Loading capacity(T): 60-80 Ton

Axle: 3 axle, 13T/16T, FUWA / BPW / TITAN Brand

Rim: 8.0-20

Tire: 12 units, 11.00R20

Suspension: Mechanical suspension

Spring leaf: 90(W)mmx13(Thickness)mmx10 layers

Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)

Landing gear: JOST brand

Main beam: Height: 500mm, Upper plate: 20mm, Middle plate: 12mm, Lower plate: 20mm, Material: Q345B steel.

Bottom Platform: 5mm thick checkered plate

Ramp: hydraulic type

Gooseneck: Optional

ABS: Optional

Valve: WABCO valve

Light: LED light (specially intended for oversea markets)

3 Axle Low Bed Trailer Truck | Low Bed Trailer Manufacturers



Through these videos, you can learn about different types of lowbed semi-trailers, as well as the process, testing, packaging and customer feedback, etc.



3 Axle 80 Ton Low Bed Truck



Welcome to leave your inquiry! We will provide more details, price, catalog, drawing, videos for you!
